L3Harris is a global supplier of status and elapsed time indicators for the military and aerospace markets.
Our products include a wide variety of the following indicators:
Nonvolatile Fault Indicators
| Models | Environ Sealed | Magnetic Latching | Self- Restore |
Manual Reset | Elec Reset |
Small/ Lightweight |
Comments |
| Miniature BITE Indicators | |||||||
| BHG/BHGD | ✔ | ✔ | - | - | - | ✔ | High visibility; reliable |
| BIS | ✔ | - | ✔ | - | - | ✔ | Sunlight readable; reliable |
Nonvolatile Fault Indicators
| Models | Environ Sealed | Magnetic Latching | Manual Reset |
Elec Reset |
Rear- Mount |
Panel- Mount |
Latched Switch |
Comments |
| BITE Indicators | ||||||||
|
MI 57DA |
✔ | ✔ | - | ✔ | ✔ | - | - | Positive Identification |
|
MI 51LP* |
✔ | ✔ | ✔ | - | - | ✔ | - | Low Power; 50mW sensitivity |
|
MI61SA, RA |
✔ | ✔ | ✔ | - | - | ✔ | - | MIL-SPEC MIL-PRF-83287/1 |
| MI61,LD, M* | ✔ | ✔ | - | - | - | ✔ | - | Optional legend display |
| Large Display Fault Indicators | ||||||||
| CI 75*** | - | ✔ | - | ✔ | - | ✔ | - | Single coil; low power/cost |
| CID 75*** | - | ✔ | - | ✔ | - | ✔ | - | Dual coil; low power/cost |
| Manual Reset Pop-Up Indicators | ||||||||
| PL 25 AC | ✔ | ✔ | ✔ | - | - | - | - | - |
| PL 25 DC | ✔ | ✔ | ✔ | - | - | - | - | - |
* = Product Discontinuance Notification MI61M, MI61LD, MI51SMS, MI51LP, D16D
**= Product Discontinuance Notification CI75, CID75 product lines
| Models | Environ Sealed |
Panel Seal |
Rear- mount |
Panel- Mount |
Internal Resistors |
Wide Operating Voltage |
Night Vision |
Infrared Secure |
High Brightness |
EMI Shielded |
Tri- Color Bi- Color LED |
| ML1600² | ✔ | - | - | ✔ | ✔ | - | - | - | - | - | - |
| ML1610 | ✔ | ✔ | - | ✔ | - | - | - | - | - | - | - |
| ML16184 | ✔ | - | - | ✔ | - | - | - | ✔ | - | ✔ | - |
| ML16194,9 | ✔ | - | - | ✔ | - | - | - | ✔ | - | ✔ | - |
| MLD16194,5 | ✔ | - | - | ✔ | - | - | - | ✔ | - | ✔ | - |
| ML1620/ML16302 | ✔ | ✔ | - | ✔ | ✔ | - | - | - | - | ✔ | - |
| ML1620-S/ML1630-S | ✔ | ✔ | - | ✔ | - | - | - | - | - | ✔ | - |
| ML1622/ML16322 | ✔ | ✔ | - | ✔ | ✔ | - | - | - | - | ✔ | B |
| ML1623-S/ML1633-S1,2 | ✔ | ✔ | - | ✔ | ✔ | - | - | - | - | ✔ | B |
| ML16318 | ✔ | ✔ | ✔ | - | - | - | - | - | - | ✔ | T |
| ML1634 | ✔ | ✔ | ✔ | - | - | - | - | - | - | ✔ | B |
| ML16351 | ✔ | ✔ | ✔ | - | - | - | - | - | - | ✔ | B |
| ML1636² | ✔ | ✔ | ✔ | - | ✔ | - | - | - | - | ✔ | - |
| ML1636U | ✔ | ✔ | ✔ | - | - | - | - | - | ✔ | ✔ | - |
| ML1638³ | ✔ | ✔ | ✔ | - | - | - | ✔ | - | - | ✔ | - |
| ML1638 Bi-Color1,3 | ✔ | ✔ | ✔ | - | - | - | ✔ | - | - | ✔ | B |
| ML16407 | ✔ | ✔ | - | ✔ | - | - | - | - | - | ✔ | - |
| ML1662³ | ✔ | ✔ | - | ✔ | - | - | ✔ | - | - | ✔ | - |
| ML2030E6 | ✔ | ✔ | - | ✔ | - | - | - | - | - | ✔ | - |
| ML20318 | ✔ | ✔ | - | ✔ | - | - | - | - | - | ✔ | T |
| ML2038E³ | ✔ | ✔ | - | ✔ | - | - | ✔ | - | - | ✔ | - |
| ML4036 | ✔ | ✔ | ✔ | - | - | ✔ | - | - | ✔ | ✔ | - |
Notes:
1 3-Leaded
2 Internal Resistors for 5VDC to 28VDC usage
3 MIL-L-85762A
4 CECOM Secure Lighting
5 Dimmable Filter Feature
6 MIL-DTL3661
7 DESC Drawing 85122
8 4-Leaded
9 DESC Drawing 87019
The DYNATIME DC hour meter was developed to meet the difficult requirements of most military and aerospace applications. They provide a wide range of supply voltage options and are packaged in a hermetically sealed miniature enclosure. This rugged design meets or exceeds an array of tough environmental specifications including shock, vibration and temperature.
In addition, DYNATIME Hour Meters have been approved to MIL-M-7793. A variety of mounting configurations are also available.
See Standard Cases & Mounts and Pin Headers information.
Cleared for Public Domain Release by Directorate of Freedom of Information and Security (DFOISR), dated April 17, 2000, reference number 00-S-1235
Qualified to MIL-M-7793*
Low Voltage Models Available
*See the Military Cross Reference for more military qualified models.
Meters meet or exceed applicable requirements of MIL-M-7793 M7793/1,/2,/5 and MS21341 A & B. Special ratings and configurations are also available.
The DYNATIME AC hour meter was developed to meet the most difficult requirements of many military and aerospace applications. Available in 400 Hz and 60 Hz configurations, the recently upgraded DYNATIME series hour meters meet or exceed an array of tough environmental specifications including shock, vibration and temperature.
In addition, it has been approved to MIL-M-7793. A variety of mounting configurations are available.
See Standard Cases & Mounts and Pin Headers information. We also welcome inquires for special requirements.
Cleared for Public Domain Release by Directorate of Freedom of Information and Security (DFOISR), dated April 17, 2000, reference number 00-S-1235
Qualified to MIL-M-7793*
*See the Military Cross Reference for more military qualified models.
The meters meet or exceed applicable requirements of MIL-M-7793 M7793/3, /4, /6, /8, /9, /10 (if QPL'd) MS27650 & 27651. Special ratings and configurations are also available.
DDS100 solid state Hour Meters have been developed to meet the most difficult requirements of many military and aerospace applications. In one PCB mount package, the DDS100 provides highly reliable means of monitoring the system. All connections are made via printed wiring and the output brought to a data collection point for system reading or to a single dedicated connector.
Elapsed Time is read from the M7793/13-1 meter by mating the printed wiring board connections with the M7793/12-1 reader's connector and operating the reader. Time range is 99999.99 hours. In addition, the DDS100 has been approved to MIL-M-7793.
Cleared by DoD/OFOISR for public release under reference number 06-S-1341 on April 20, 2006.
DDS100 solid state Elapsed Time Indicators have been developed to meet the most difficult requirements of many military and aerospace applications. In one PCB mount package, the DDS100 provides highly reliable means of monitoring the system. All connections are made via printed wiring and the output brought to a data collection point for system reading or to a single dedicated connector.
Elapsed Time is read from the M7793/13-1 meter by mating the printed wiring board connections with the M7793/12-1 reader’s connector and operating the reader. Time range is 99999.99 hours. In addition, the DDS100 has been approved to MIL-M-7793/13.
The DDS101 solid state Events Counter records counts when the unit receives power for greater than 5 seconds. Power-on times of less than 4 seconds will not cause the counter to increment, allowing the count to be read without affecting the results. The count range is 9,999,999.
All connections, data collection, and the display of counts are made in the same manner as the DDS100 Elapsed Time Indicator. The DDS101 Event Counter meets the requirements of M7793 and the same environmental, mechanical, and electrical specifications as the DDS100.
The meters meet or exceed applicable requirements of MIL-M-7793 M7793/13. Other ratings and configurations are also available.
| MIL SPEC NUMBER M7793/1 |
CROSS REFERENCE 4 Digit Short Square 12 & 28VDC |
MIL SPEC NUMBER M7793/2 |
CROSS REFERENCE 4 Digit Short Round 12 & 28VDC |
| M7793/1-001 | D16C8C2 | M7793/2-001 | D16B8C2 |
| M7793/1-002 | D16C8A | M7793/2-002 | D16B8A |
| M7793/1-003 | D16C8CA-136 | M7793/2-003 | D16B8CA-136 |
| M7793/1-004 | D16C8CB-136 | M7793/2-004 | D16B8CB-136 |
| M7793/1-005 | D16C8CC-136 | M7793/2-005 | D16B8CC-136 |
| M7793/1-006 | D16C8CD-136 | M7793/2-006 | D16B8CD-136 |
| M7793/1-007 | D16C8CE-136 | M7793/2-007 | D16B8CE-136 |
| M7793/1-008 | D16C8CF-136 | M7793/2-008 | D16B8CF-136 |
| M7793/1-009 | D16C8CG-136 | M7793/2-009 | D16B8CG-136 |
| M7793/1-010 | D16C8CH-136 | M7793/2-010 | D16B8CH-136 |
| M7793/1-011 | D16C8CI-136 | M7793/2-011 | D16B8CI-136 |
| M7793/1-012 | D16C8CJ-136 | M7793/2-012 | D16B8CJ-136 |
| M7793/1-013 | D16C8CK-136 | M7793/2-013 | D16B8CK-136 |
| M7793/1-014 | D16C8CL-136 | M7793/2-014 | D16B8CL-136 |
| M7793/1-015 | D16C8CM-136 | M7793/2-015 | D16B8CM-136 |
| M7793/1-016 | D16C8CN-136 | M7793/2-016 | D16B8CN-136 |
| M7793/1-017 | D16C8CO-136 | M7793/2-017 | D16B8CO-136 |
| M7793/1-018 | D16C8CP-136 | M7793/2-018 | D16B8CP-136 |
| M7793/1-019 | D16C8CR-136 | M7793/2-019 | D16B8CR-136 |
| M7793/1-020 | D16C8CS-136 | M7793/2-020 | D16B8CS-136 |
| M7793/1-021 | D16C8CT-136 | M7793/2-021 | D16B8CT-136 |
| M7793/1-022 | D16C8CT 8-136 | M7793/2-022 | D16B8CT-8-136 |
| M7793/1-023 | D16C8CU-136 | M7793/2-023 | D16B8CU-136 |
| M7793/1-024 | D16C8CU-8-136 | M7793/2-024 | D16B8CU-8-136 |
| M7793/1-025 | D16C8CV-136 | M7793/2-025 | D16B8CV-136 |
| M7793/1-026 | D16C8CV-8-136 | M7793/2-026 | D16B8CV-8-136 |
| M7793/1-027 | D16C8CW-136 | M7793/2-027 | D16B8CW-136 |
| M7793/1-028 | D16C8CW-8-136 | M7793/2-028 | D16B8CW-8-136 |
|
MIL SPEC NUMBER |
CROSS REFERENCE 4 Digit Round & Square 12 & 26 VDC |
MIL SPEC NUMBER |
CROSS REFERENCE 4 Digit Round & Square 115 VAC/400Hz. |
| M7793/5-001 | 16B8C2 (Rnd) | M7793/6-001 | D95B8C2 (Rnd) |
| M7793/5-002 | 16C8C2 (Sqr) | M7793/6-002 | D95C8C2 (Sqr) |
|
MS21341A |
MS21341 B |
||
|
MS21341A-01 |
D16C8CA-16 |
MS21341 B-01 |
16C8CA-16 |
| MS21341A-02 | D16C8CB-16 | MS21341 B-02 | 16C8CB-16 |
| MS21341A-03 | D16C8CC-16 | MS21341 B-03 | 16C8CC-16 |
| MS21341A-04 | D16C8CD-16 | MS21341 B-04 | 16C8CD-16 |
| MS21341A-05 | D16C8CE-16 | MS21341 B-05 | 16C8CE-16 |
| MS21341A-06 | D16C8CF-16 | MS21341 B-06 | 16C8CF-16 |
| MS21341A-07 | D16C8CG-16 | MS21341 B-07 | 16C8CG-16 |
| MS21341A-08 | D16C8CH-16 | MS21341 B-08 | 16C8CH-16 |
| MS21341A-09 | D16C8CI-16 | MS21341 B-09 | 16C8CI-16 |
| MS21341A-10 | D16C8CJ-16 | MS21341 B-10 | 16C8CJ -16 |
| MS21341A-11 | D16C8CK-16 | MS21341 B-11 | 16C8CK-16 |
| MS21341A-12 | D16C8CL-16 | MS21341 B-12 | 16C8CL-16 |
| MS21341A-13 | D16C8CM-16 | MS21341 B-13 | 16C8CM-16 |
| MS21341A-14 | D16C8CN-16 | MS21341 B-14 | 16C8CN-16 |
| MS21341A-15 | D16C8CO-16 | MS21341 B-15 | 16C8CO-16 |
| MS21341A-16 | D16C8CP-16 | MS21341 B-16 | 16C8CP-16 |
| MS21341A-17 | D16C8CR-16 | MS21341 B-17 | 16C8CR-16 |
| MS21341A-18 | D16C8CS-16 | MS21341 B-18 | 16C8CS-16 |
| MS21341A-19 | D16C8CT-16 | MS21341 B-19 | 16C8CT-16 |
| MS21341A-20 | D16C8CT-8-16 | MS21341 B-20 | 16C8CT-8-16 |
| MS21341A-21 | D168CU-16 | MS21341 B-21 | 16C8CU-16 |
| MS21341A-22 | D16C8CU-8-16 | MS21341 B-22 | 16C8CU-8-16 |
| MS21341A-23 | D16C8CV-16 | MS21341 B-23 | 16C8CV-16 |
| MS21341A-24 | D16C8CV-8-16 | MS21341 B-24 | 16C8CV-8-16 |
| MS21341A-25 | D16C8CW-16 | MS21341 B-25 | 16C8CW-16 |
| MS21341A-26 | D16C8CW-8-16 | MS21341 B-26 | 16C8CW-8-16 |
| MIL SPEC NUMBER M7793/3 |
CROSS REFERENCE 4 Digit Short Square 115VAC/400Hz. |
MIL SPEC NUMBER M7793/4 |
CROSS REFERENCE 4 Digit Short Round 115VAC/400Hz. |
| M7793/3-001 | D92C8C2 | M7793/4-001 | D92B8C2 |
| M7793/3-002 | D92C8A | M7793/4-002 | D92B8A |
| M7793/3-003 | D92C8CA-136 | M7793/4-003 | D92B8CA-136 |
| M7793/3-004 | D92C8CB-136 | M7793/4-004 | D92B8CB-136 |
| M7793/3-005 | D92C8CC-136 | M7793/4-005 | D92B8CC-136 |
| M7793/3-006 | D92C8CD-136 | M7793/4-006 | D92B8CD-136 |
| M7793/3-007 | D92C8CE-136 | M7793/4-007 | D92B8CE-136 |
| M7793/3-008 | D92C8CF-136 | M7793/4-008 | D92B8CF-136 |
| M7793/3-009 | D92C8CG-136 | M7793/4-009 | D92B8CG-136 |
| M7793/3-010 | D92C8CH-136 | M7793/4-010 | D92B8CH-136 |
| M7793/3-011 | D92C8C1-136 | M779 /4-011 | D92B8CI-136 |
| M7793/3-012 | D92C8CJ-136 | M7793/4-012 | D92B8CJ-136 |
| M7793/3-013 | D92C8CK-136 | M7793/4-013 | D92B8CK-136 |
| M7793/3-014 | D92C8CL-136 | M7793/4-014 | D92B8CL-136 |
| M7793/3-015 | D92C8CM-136 | M7793/4-015 | D92B8CM-136 |
| M7793/3-016 | D92C8CN-136 | M7793/4-016 | D92B8CN-136 |
| M7793/3-017 | D92C8CO-136 | M7793/4-017 | D92B8CO-136 |
| M7793/3-018 | D92C8CP-136 | M7793/4-018 | D92B8CP-136 |
| M7793/3-019 | D92C8CR-136 | M7793/4-019 | D92B8CR-136 |
| M7793/3-020 | D92C8CS-136 | M7793/4-020 | D92B8CS-136 |
| M7793/3-021 | D92C8CT-136 | M7793/4-021 | D92B8CT-136 |
| M7793/3-022 | D92C8CT-8-136 | M7793/4-022 | D92B8CT-8-136 |
| M7793/3-023 | D92C8CU-136 | M7793/4-023 | D92B8CU-136 |
| M7793/3-024 | D92C8CU-8-136 | M7793/4-024 | D92B8CU-8-136 |
| M7793/3-025 | D92C8CV-136 | M7793/4-025 | D92B8CV-136 |
| M7793/3-026 | D92C8CV-8-136 | M7793/4-026 | D92B8CV-8-136 |
| M7793/3-027 | D92C8CW-136 | M7793/4-027 | D92B8CW-136 |
| M7793/3-028 | D92C8CW-8-136 | M7793/4-028 | D92B8CW-8-136 |
| MIL SPEC NUMBER | CROSS REFERENCE | MIL SPEC NUMBER | CROSS REFERENCE |
| M7793/8-001A | D95G8N3A-105 | M7793/9-001A | D95G8N4D-105 |
| M7793/8-002A | D92G8N3A-105 | M7793/9-002A | D95G9N4D-105 |
| M7793/8-003A | D95G9N3A-105 | M7793/10-001A | D92G8N4D-105 |
| M7793/8-004A | D92G9N3A-105 | M7793/10-002A | D92G9N4D-105 |
| M7793/13-001 | 2301000-1 | M7793/13 | DDS232 |
| M7793/14-001 | 2301021-1 |
| MIL SPEC NUMBER | CROSS REFERENCE | MIL SPEC NUMBER | CROSS REFERENCE |
| MS27650-01A | D25C8C7A-16 | MS27650-01B | D25C8C7A-1-16 |
| MS27650-02A | D25C8C7B-16 | MS27650-02B | D25C8C7B-1-16 |
| MS27650-03A | D25C8C7C-16 | MS27650-03B | D25C8C7C-1-16 |
| MS27650-04A | D25C8C7D-16 | MS27650-04B | D25C8C7D-1-16 |
| MS27650-05A | D25C8C7E-16 | MS27650-05B | D25C8C7E-1-16 |
| MS27650-06A | D25C8C7F-16 | MS27650-06B | D25C8C7F-1-16 |
| MS27650-07A | D25C8C7G-16 | MS27650-07B | D25C8C7G-1-16 |
| MS27650-08A | D25C8C7H-16 | MS27650-08B | D25C8C7H-1-16 |
| MS27650-09A | D25C8C7I-16 | MS27650-09B | D25C8C7I-1-16 |
| MS27650-010A | D25C8C7J-16 | MS27650-10B | D25C8C7J-1 -16 |
| MS27650-011A | D25C8C7K-16 | MS27650-11B | D25C8C7K-1-16 |
| MS27650-012A | D25C8C7L-16 | MS27650-12B | D25C8C7L-1-16 |
| MS27650-013A | D25C8C7M-16 | MS27650-13B | D25C8C7M-1-16 |
| MS27650-014A | D25C8C7N-16 | MS27650-14B | D25C8C7N-1-16 |
| MS27650-015A | D25C8C7O-16 | MS27650-15B | D25C8C7O-1-16 |
| MS27650-016A | D25C8C7P-16 | MS27650-16B | D25C8C7P-1-16 |
| MS27650-017A | D25C8C7R-16 | MS27650-17B | D25C8C7R-1-16 |
| MS27650-018A | D25C8C7S-16 | MS27650-18B | D25C8C7S-1-16 |
| MS27650-019A | D25C8C7T-16 | MS27650-19B | D25C8C7T-1-16 |
| MS27650-020A | D25C8C7-8-16 | MS27650-20B | D25C8C7T-8-16 |
| MS27650-021A | D25C8C7U-16 | MS27650-21B | D25C8C7U-1-16 |
| MS27650-022A | D25C8C7U-8-16 | MS27650-22B | D25C8C7U-8-1-16 |
| MS27650-023A | D25C8C7V-16 | MS27650-23B | D25C8C7V-1-16 |
| MS27650-024A | D25C8C7V-8-16 | MS27650-24B | D25C8C7V-8-1-16 |
| MS27650-025A | D25C8C7W-16 | MS27650-25B | D25C8C7W-1-16 |
| MS27650-026A | D25C8C7W-8-16 | MS27650-26B | D25C8C7W-8-1-16 |
| MIL SPEC NUMBER | CROSS REFERENCE | MIL SPEC NUMBER | CROSS REFERENCE |
| MS27650-01E | D25C8WA-16 | MS27650-01F | D25C8WA-1-16 |
| MS27650-02E | D25C8WB-16 | MS27650-02F | D25C8WB-1-16 |
| MS27650-03E | D25C8WC-16 | MS27650-03F | D25C8WC-1-16 |
| MS27650-04E | D25C8WD-16 | MS27650-04F | D25C8WD-1-16 |
| MS27650-05E | D25C8WE-16 | MS27650-05F | D25C8WE-1-16 |
| MS27650-06E | D25C8WF-16 | MS27650-06F | D25C8WF-1-16 |
| MS27650-07E | D25C8WG-16 | MS27650-07F | D25C8WG-1-16 |
| MS27650-08E | D25C8WH-16 | MS27650-08F | D25C8WH-1-16 |
| MS27650-09E | D25C8WI-16 | MS27650-09F | D25C8WI-1-16 |
| MS27650-010E | D25C8WJ-16 | MS27650-10F | D25C8WJ-1 -16 |
| MS27650-011E | D25C8WK-16 | MS27650-11F | D25C8WK-1-16 |
| MS27650-012E | D25C8WL-16 | MS27650-12F | D25C8WL-1-16 |
| MS27650-013E | D25C8WM-16 | MS27650-13F | D25C8WM-1-16 |
| MS27650-014E | D25C8WN-16 | MS27650-14F | D25C8WN-1-16 |
| MS27650-015E | D25C8WO-16 | MS27650-15F | D25C8WO-1-16 |
| MS27650-016E | D25C8WP-16 | MS27650-16F | D25C8WP-1-16 |
| MS27650-017E | D25C8WR-16 | MS27650-17F | D25C8WR-1-16 |
| MS27650-018E | D25C8WS-16 | MS27650-18F | D25C8WS-1-16 |
| MS27650-019E | D25C8WT-16 | MS27650-19F | D25C8WT-1-16 |
| MS27650-020E | D25C8WT-8-16 | MS27650-20F | D25C8WT-8-16 |
| MS27650-021E | D25C8WU-16 | MS27650-21F | D25C8WU-1-16 |
| MS27650-022E | D25C8WU-8-16 | MS27650-22F | D25C8WU-8-1-16 |
| MS27650-023E | D25C8WV-16 | MS27650-23F | D25C8WV-1-16 |
| MS27650-024E | D25C8WV-8-16 | MS27650-24F | D25C8WV-8-1-16 |
| MS27650-025E | D25C8WW-16 | MS27650-25F | D25C8WW-1-16 |
| MS27650-026E | D25C8WW-8-16 | MS27650-26F | D25C8WW-8-1-16 |
| MIL SPEC NUMBER | CROSS REFERENCE | MIL SPEC NUMBER | CROSS REFERENCE |
| MS27650-01C | D25C8CA-16 | MS27650-01D | D25C8CA-1-16 |
| MS27650-02C | D25C8CB-16 | MS27650-02D | D25C8CB-1-16 |
| MS27650-03C | D25C8CC-16 | MS27650-03D | D25C8CC-1-16 |
| MS27650-04C | D25C8CD-16 | MS27650-04D | D25C8CD-1-16 |
| MS27650-05C | D25C8CE-16 | MS27650-05D | D25C8CE-1-16 |
| MS27650-06C | D25C8CF-16 | MS27650-06D | D25C8CF-1-16 |
| MS27650-07C | D25C8CG-16 | MS27650-07D | D25C8CG-1-16 |
| MS27650-08C | D25C8CH-16 | MS27650-08D | D25C8CH-1-16 |
| MS27650-09C | D25C8CI-16 | MS27650-09D | D25C8CI-1-16 |
| MS27650-010C | D25C8CJ-16 | MS27650-10D | D25C8CJ-1 -16 |
| MS27650-011C | D25C8CK-16 | MS27650-11D | D25C8CK-1-16 |
| MS27650-012C | D25C8CL-16 | MS27650-12D | D25C8CL-1-16 |
| MS27650-013C | D25C8CM-16 | MS27650-13D | D25C8CM-1-16 |
| MS27650-014C | D25C8CN-16 | MS27650-14D | D25C8CN-1-16 |
| MS27650-015C | D25C8CO-16 | MS27650-15D | D25C8CO-1-16 |
| MS27650-016C | D25C8CP-16 | MS27650-16D | D25C8CP-1-16 |
| MS27650-017C | D25C8CR-16 | MS27650-17D | D25C8CR-1-16 |
| MS27650-018C | D25C8CS-16 | MS27650-18D | D25C8CS-1-16 |
| MS27650-019C | D25C8CT-16 | MS27650-19D | D25C8CT-1-16 |
| MS27650-020C | D25C8C-8-16 | MS27650-20D | D25C8CT-8-16 |
| MS27650-021C | D25C8CU-16 | MS27650-21D | D25C8CU-1-16 |
| MS27650-022C | D25C8CU-8-16 | MS27650-22D | D25C8CU-8-1-16 |
| MS27650-023C | D25C8CV-16 | MS27650-23D | D25C8CV-1-16 |
| MS27650-024C | D25C8CV-8-16 | MS27650-24D | D25C8CV-8-1-16 |
| MS27650-025C | D25C8CW-16 | MS27650-25D | D25C8CW-1-16 |
| MS27650-026C | D25C8CW-8-16 | MS27650-26D | D25C8CW-8-1-16 |
| MIL SPEC NUMBER | CROSS REFERENCE | MIL SPEC NUMBER | CROSS REFERENCE |
| MS27650-01G | D25C8VA-16 | MS27650-01H | D25C8VA-1-16 |
| MS27650-02G | D25C8VB-16 | MS27650-02H | D25C8VB-1-16 |
| MS27650-03G | D25C8VC-16 | MS27650-03H | D25C8VC-1-16 |
| MS27650-04G | D25C8VD-16 | MS27650-04H | D25C8VD-1-16 |
| MS27650-05G | D25C8VE-16 | MS27650-05H | D25C8VE-1-16 |
| MS27650-06G | D25C8VF-16 | MS27650-06H | D25C8VF-1-16 |
| MS27650-07G | D25C8VG-16 | MS27650-07H | D25C8VG-1-16 |
| MS27650-08G | D25C8VH-16 | MS27650-08H | D25C8VH-1-16 |
| MS27650-09G | D25C8VI-16 | MS27650-09H | D25C8VI-1-16 |
| MS27650-010G | D25C8VJ-16 | MS27650-10H | D25C8VJ-1 -16 |
| MS27650-011G | D25C8VK-16 | MS27650-11H | D25C8VK-1-16 |
| MS27650-012G | D25C8VL-16 | MS27650-12H | D25C8VL-1-16 |
| MS27650-013G | D25C8VM-16 | MS27650-13H | D25C8VM-1-16 |
| MS27650-014G | D25C8VN-16 | MS27650-14H | D25C8VN-1-16 |
| MS27650-015G | D25C8VO-16 | MS27650-15H | D25C8VO-1-16 |
| MS27650-016G | D25C8VP-16 | MS27650-16H | D25C8VP-1-16 |
| MS27650-017G | D25C8VR-16 | MS27650-17H | D25C8VR-1-16 |
| MS27650-018G | D25C8VS-16 | MS27650-18H | D25C8VS-1-16 |
| MS27650-019G | D25C8VT-16 | MS27650-19H | D25C8VT-1-16 |
| MS27650-020G | D25C8VT-8-16 | MS27650-20H | D25C8VT-8-16 |
| MS27650-021G | D25C8VU-16 | MS27650-21H | D25C8VU-1-16 |
| MS27650-022G | D25C8VU-8-16 | MS27650-22H | D25C8VU-8-1-16 |
| MS27650-023G | D25C8VV-16 | MS27650-23H | D25C8VV-1-16 |
| MS27650-024G | D25C8VV-8-16 | MS27650-24H | D25C8VV-8-1-16 |
| MS27650-025G | D25C8VW-16 | MS27650-25H | D25C8VW-1-16 |
| MS27650-026G | D25C8VW-8-16 | MS27650-26H | D25C8VW-8-1-16 |
| MIL SPEC NUMBER | CROSS REFERENCE | MIL SPEC NUMBER | CROSS REFERENCE |
| MS27651-01A | D95C8C7A-16 | MS27651-01B | D95C8C7A-1-16 |
| MS27651-02A | D95C8C7B-16 | MS27651-02B | D95C8C7B-1-16 |
| MS27651-03A | D95C8C7C-16 | MS27651-03B | D95C8C7C-1-16 |
| MS27651-04A | D95C8C7D-16 | MS27651-04B | D95C8C7D-1-16 |
| MS27651-05A | D95C8C7E-16 | MS27651-05B | D95C8C7E-1-16 |
| MS27651-06A | D95C8C7F-16 | MS27651-06B | D95C8C7F-1-16 |
| MS27651-07A | D95C8C7G-16 | MS27651-07B | D95C8C7G-1-16 |
| MS27651-08A | D95C8C7H-16 | MS27651-08B | D95C8C7H-1-16 |
| MS27651-09A | D95C8C7I-16 | MS27651-09B | D95C8C7I-1-16 |
| MS27651-010A | D95C8C7J-16 | MS27651-10B | D95C8C7J-1 -16 |
| MS27651-011A | D95C8C7K-16 | MS27651-11B | D95C8C7K-1-16 |
| MS27651-012A | D95C8C7L-16 | MS27651-12B | D95C8C7L-1-16 |
| MS27651-013A | D95C8C7M-16 | MS27651-13B | D95C8C7M-1-16 |
| MS27651-014A | D95C8C7N-16 | MS27651-14B | D95C8C7N-1-16 |
| MS27651-015A | D95C8C7O-16 | MS27651-15B | D95C8C7O-1-16 |
| MS27651-016A | D95C8C7P-16 | MS27651-16B | D95C8C7P-1-16 |
| MS27651-017A | D95C8C7R-16 | MS27651-17B | D95C8C7R-1-16 |
| MS27651-018A | D95C8C7S-16 | MS27651-18B | D95C8C7S-1-16 |
| MS27651-019A | D95C8C7T-16 | MS27651-19B | D95C8C7T-1-16 |
| MS27651-020A | D95C8C7-8-16 | MS27651-20B | D95C8C7T-8-16 |
| MS27651-021A | D95C8C7U-16 | MS27651-21B | D95C8C7U-1-16 |
| MS27651-022A | D95C8C7U-8-16 | MS27651-22B | D95C8C7U-8-1-16 |
| MS27651-023A | D95C8C7V-16 | MS27651-23B | D95C8C7V-1-16 |
| MS27651-024A | D95C8C7V-8-16 | MS27651-24B | D95C8C7V-8-1-16 |
| MS27651-025A | D95C8C7W-16 | MS27651-25B | D95C8C7W-1-16 |
| MS27651-026A | D95C8C7W-8-16 | MS27651-26B |
D95C8C7W-8-1-1 |
| MIL SPEC NUMBER | CROSS REFERENCE | MIL SPEC NUMBER | CROSS REFERENCE |
| MS27651-01E | D95C8WA-16 | MS27651-01F | D95C8WA-1-16 |
| MS27651-02E | D95C8WB-16 | MS27651-02F | D95C8WB-1-16 |
| MS27651-03E | D95C8WC-16 | MS27651-03F | D95C8WC-1-16 |
| MS27651-04E | D95C8WD-16 | MS27651-04F | D95C8WD-1-16 |
| MS27651-05E | D95C8WE-16 | MS27651-05F | D95C8WE-1-16 |
| MS27651-06E | D95C8WF-16 | MS27651-06F | D95C8WF-1-16 |
| MS27651-07E | D95C8WG-16 | MS27651-07F | D95C8WG-1-16 |
| MS27651-08E | D95C8WH-16 | MS27651-08F | D95C8WH-1-16 |
| MS27651-09E | D95C8WI-16 | MS27651-09F | D95C8WI-1-16 |
| MS27651-010E | D95C8WJ-16 | MS27651-10F | D95C8WJ-1 -16 |
| MS27651-011E | D95C8WK-16 | MS27651-11F | D95C8WK-1-16 |
| MS27651-012E | D95C8WL-16 | MS27651-12F | D95C8WL-1-16 |
| MS27651-013E | D95C8WM-16 | MS27651-13F | D95C8WM-1-16 |
| MS27651-014E | D95C8WN-16 | MS27651-14F | D95C8WN-1-16 |
| MS27651-015E | D95C8WO-16 | MS27651-15F | D95C8WO-1-16 |
| MS27651-016E | D95C8WP-16 | MS27651-16F | D95C8WP-1-16 |
| MS27651-017E | D95C8WR-16 | MS27651-17F | D95C8WR-1-16 |
| MS27651-018E | D95C8WS-16 | MS27651-18F | D95C8WS-1-16 |
| MS27651-019E | D95C8WT-16 | MS27651-19F | D95C8WT-1-16 |
| MS27651-020E | D95C8WT-8-16 | MS27651-20F | D95C8WT-8-16 |
| MS27651-021E | D95C8WU-16 | MS27651-21F | D95C8WU-1-16 |
| MS27651-022E | D95C8WU-8-16 | MS27651-22F | D95C8WU-8-1-16 |
| MS27651-023E | D95C8WV-16 | MS27651-23F | D95C8WV-1-16 |
| MS27651-024E | D95C8WV-8-16 | MS27651-24F | D95C8WV-8-1-16 |
| MS27651-025E | D95C8WW-16 | MS27651-25F | D95C8WW-1-16 |
| MS27651-026E | D95C8WW-8-16 | MS27651-26F | D95C8WW-8-1-16 |
| MIL SPEC NUMBER | CROSS REFERENCE | MIL SPEC NUMBER | CROSS REFERENCE |
| MS27651-01C | D95C8CA-16 | MS27651-01D | D95C8CA-1-16 |
| MS27651-02C | D95C8CB-16 | MS27651-02D | D95C8CB-1-16 |
| MS27651-03C | D95C8CC-16 | MS27651-03D | D95C8CC-1-16 |
| MS27651-04C | D95C8CD-16 | MS27651-04D | D95C8CD-1-16 |
| MS27651-05C | D95C8CE-16 | MS27651-05D | D95C8CE-1-16 |
| MS27651-06C | D95C8CF-16 | MS27651-06D | D95C8CF-1-16 |
| MS27651-07C | D95C8CG-16 | MS27651-07D | D95C8CG-1-16 |
| MS27651-08C | D95C8CH-16 | MS27651-08D | D95C8CH-1-16 |
| MS27651-09C | D95C8CI-16 | MS27651-09D | D95C8CI-1-16 |
| MS27651-010C | D95C8CJ-16 | MS27651-10D | D95C8CJ-1 -16 |
| MS27651-011C | D95C8CK-16 | MS27651-11D | D95C8CK-1-16 |
| MS27651-012C | D95C8CL-16 | MS27651-12D | D95C8CL-1-16 |
| MS27651-013C | D95C8CM-16 | MS27651-13D | D95C8CM-1-16 |
| MS27651-014C | D95C8CN-16 | MS27651-14D | D95C8CN-1-16 |
| MS27651-015C | D95C8CO-16 | MS27651-15D | D95C8CO-1-16 |
| MS27651-016C | D95C8CP-16 | MS27651-16D | D95C8CP-1-16 |
| MS27651-017C | D95C8CR-16 | MS27651-17D | D95C8CR-1-16 |
| MS27651-018C | D95C8CS-16 | MS27651-18D | D95C8CS-1-16 |
| MS27651-019C | D95C8CT-16 | MS27651-19D | D95C8CT-1-16 |
| MS27651-020C | D95C8C-8-16 | MS27651-20D | D95C8CT-8-16 |
| MS27651-021C | D95C8CU-16 | MS27651-21D | D95C8CU-1-16 |
| MS27651-022C | D95C8CU-8-16 | MS27651-22D | D95C8CU-8-1-16 |
| MS27651-023C | D95C8CV-16 | MS27651-23D | D95C8CV-1-16 |
| MS27651-024C | D95C8CV-8-16 | MS27651-24D | D95C8CV-8-1-16 |
| MS27651-025C | D95C8CW-16 | MS27651-25D | D95C8CW-1-16 |
| MS27651-026C | D95C8CW-8-16 | MS27651-26D | D95C8CW-8-1-16 |
| MIL SPEC NUMBER | CROSS REFERENCE | MIL SPEC NUMBER | CROSS REFERENCE |
| MS27651-01G | D95C8VA-16 | MS27651-01H | D95C8VA-1-16 |
| MS27651-02G | D95C8VB-16 | MS27651-02H | D95C8VB-1-16 |
| MS27651-03G | D95C8VC-16 | MS27651-03H | D95C8VC-1-16 |
| MS27651-04G | D95C8VD-16 | MS27651-04H | D95C8VD-1-16 |
| MS27651-05G | D95C8VE-16 | MS27651-05H | D95C8VE-1-16 |
| MS27651-06G | D95C8VF-16 | MS27651-06H | D95C8VF-1-16 |
| MS27651-07G | D95C8VG-16 | MS27651-07H | D95C8VG-1-16 |
| MS27651-08G | D95C8VH-16 | MS27651-08H | D95C8VH-1-16 |
| MS27651-09G | D95C8VI-16 | MS27651-09H | D95C8VI-1-16 |
| MS27651-010G | D95C8VJ-16 | MS27651-10H | D95C8VJ-1 -16 |
| MS27651-011G | D95C8VK-16 | MS27651-11H | D95C8VK-1-16 |
| MS27651-012G | D95C8VL-16 | MS27651-12H | D95C8VL-1-16 |
| MS27651-013G | D95C8VM-16 | MS27651-13H | D95C8VM-1-16 |
| MS27651-014G | D95C8VN-16 | MS27651-14H | D95C8VN-1-16 |
| MS27651-015G | D95C8VO-16 | MS27651-15H | D95C8VO-1-16 |
| MS27651-016G | D95C8VP-16 | MS27651-16H | D95C8VP-1-16 |
| MS27651-017G | D95C8VR-16 | MS27651-17H | D95C8VR-1-16 |
| MS27651-018G | D95C8VS-16 | MS27651-18H | D95C8VS-1-16 |
| MS27651-019G | D95C8VT-16 | MS27651-19H | D95C8VT-1-16 |
| MS27651-020G | D95C8VT-8-16 | MS27651-20H | D95C8VT-8-16 |
| MS27651-021G | D95C8VU-16 | MS27651-21H | D95C8VU-1-16 |
| MS27651-022G | D95C8VU-8-16 | MS27651-22H | D95C8VU-8-1-16 |
| MS27651-023G | D95C8VV-16 | MS27651-23H | D95C8VV-1-16 |
| MS27651-024G | D95C8VV-8-16 | MS27651-24H | D95C8VV-8-1-16 |
| MS27651-025G | D95C8VW-16 | MS27651-25H | D95C8VW-1-16 |
| MS27651-026G | D95C8VW-8-16 | MS27651-26H | D95C8VW-8-1-16 |
L3Harris is committed to exceeding customer expectations, the first time, by utilizing the e3 business operating system and living the L3Harris values.
L3Harris designs and manufactures a wide range of high-reliability commercial and military specification electromechanical, electromagnetic and solid state status indicators. In addition, L3Harris provides custom products and solutions that meet or exceed the requirements of the U.S. and international military and aerospace markets from our company-owned manufacturing facility in Cincinnati, Ohio.
Committed to providing the highest level of quality, L3Harris has developed and maintains an ISO 9001/AS9100 certified Quality Management System. In addition, L3Harris manages a mature Lean Six Sigma program that insures continuous improvement and offers reliable and accurate product support.
All of our engineering, manufacturing and business operations are located at this single site to generate greater efficiencies, higher quality and significant cost savings.
Design and development activities are performed in new, well-equipped laboratories accommodating the various technical disciplines embodied in L3Harris products. These facilities include mechanical laboratories for the development of precision mechanisms and electro-mechanical devices as well as electronics laboratories for the development of electronic circuits, systems and equipment.
